Size:  From 1.5” to 6”

Pressure Range:  From 30inHg to 1600bar

Socket:  Brass , chrome plated

Thread:  BSP, NPT, BSPT, PT, ZG, and other special specification

Bourdon Tube:  Phosphor bronze or stainless steel material

   Lower Case :  304 St St ,316 St St material, polished or not polished, back with no screws

         Bezel:  304 St St crimped bezel or 316 St St crimped bezel,bayonet

      Window:  PC Lens or glass lens

Dial Plate:  Single , dual or three scales(Bar, Psi, Kg/ c㎡, Kpa, Mpa)

Accuracy:  3-2-3%,2.5%,1.6%,1%

      Movement:  Steel, brass or stainless steel material

         Pointer:  Aluminium or stainless steel material（adjust type）

        U-Clamp: Chrome plated or St St material

          Flange:  Chrome plated or St St material

       Restrictor:  Brass or St St material

Over Pressure:  130%
